High Quality Marine Supplies Wing Type Rubber Fender For Dock

(0 customer reviews)

Wing Type Rubber Fender Features

  1. Jerryborg-wing type rubber fender is a new type fender on the basis of D type fender, wider bottom with  embedded steel plate, double row fixing bolts, longer working life than type D fender.
  1. Higher reaction force and energy absorption than type D fender
  1. Easy to install and maintain
  1. Better anchoring capacity

Wing Type Rubber Fender Structure

Wing Type Rubber Fender Specification

Spec. sizes
H B b L Q p S h T t n
GD 300×540×1000 300 540 430 1000 150 700 165 120 82 41 2
GD 300×540×1500 300 540 430 1500 150 600 165 120 82 41 3
GD 300×540×2000 300 540 430 2000 145 570 165 120 82 41 4
GD 300×540×2500 300 540 430 2500 150 550 165 120 82 41 5
GD 300×540×3000 300 540 430 3000 150 540 165 120 82 41 6
GD 300×600×1000 300 600 490 1000 150 700 165 120 82 41 2
GD 300×600×1500 300 600 490 1500 150 600 165 120 82 41 3
GD 300×600×2000 300 600 490 2000 145 570 165 120 82 41 4
GD 300×600×2500 300 600 490 2500 150 550 165 120 82 41 5
GD 300×600×3000 300 600 490 3000 150 540 165 120 82 41 6
Categories: ,
Wing Type Rubber Fender

wing (GD) type rubber fender is designed on the basis of D type rubber fender. It is usually installed on docks or ship to counteract the collision force between the dock and the ship during berthing and to prevent damage to the ship and the dock. The fender bottom width and pre-bulit-in steel plate has been enlarged. Jerryborg is a professional manufacturer for marine products and provide a wide range of GD type rubber fenders with various dimensions.


GD type rubber fender (Wing D rubber fender) is usually regarded as an alternative to other profiles as belting for tugs and workboats. The wings are forced into a jacking angle during installation and joints of adjacent sections are blocked to achieve a smooth and continuous contact surface. With the wings sit tightly within the angles, this type of arrangement is resistant to transverse and longitudinal shear-ideal for tugs.
